Telstra 4GX Wi-Fi Plus 2 ZTE MF986C Patch Lead & Antennas

Telstra 4GX Wi-Fi Plus 2 ZTE MF986C Specifications

• Network Compatibility: 4GX LTE, Bands 1, 3, 7, 26, 28
• Chipset: Qualcomm Snapdragon SDX12-2
• Wi-Fi: Wi-Fi 802.11 b/g/n/ac 2.4GHz and 5GHz
• Dimensions: 107 x 63 x 14mm, 118g
• Battery: 3000mAh battery, user replaceable
• Operating time: Active battery up to 8 hours.
• Connectivity: USB 3.1 type C charging connection
• Operating systems: Any Wi-Fi enabled device, Windows 10, 8, MAC OS X 10.7, Linux (3.10 kernel upwards).
• SIM Card: Nano SIM, 4FF
• Display: 3 x LED indicators
• Temperature: -5ºC to +40ºC

Telstra 4GX Wi-Fi Plus 2 MF986C

The Telstra 4GX Wi-Fi Plus 2 is a powerful LTE 4G Wi-Fi hotspot that supports up to 32 users, making it an ideal solution for small to medium-sized businesses or families with multiple devices. It features Cat 6 LTE download speeds of up to 300Mbps, ensuring fast and reliable internet connectivity.

Telstra 4GX Wi-Fi Plus 2 ZTE MF986C Battery Life

The device boasts an impressive battery life of up to 8 hours, allowing users to stay connected on-the-go without worrying about running out of power. Additionally, the Telstra Data Usage Meter can be accessed via the WebGUI, making it easy to monitor and manage data usage.

Telstra 4GX Wi-Fi Plus 2 MF986C 4G Networks

The Telstra 4GX Wi-Fi Plus 2 operates on a range of frequency bands, including LTE B1, B3, B7, B26, and B28, and supports Wi-Fi 802.11 b/g/n/ac (2.4GHz & 5GHz) with 2x2 MIMO. It also features dual TS9 antenna ports for external antenna connectivity. The device is compact and lightweight, measuring 107 x 63 x 14mm and weighing 118g.

Telstra 4GX Wi-Fi Plus 2

The Telstra 4GX Wi-Fi Plus 2 is locked to the Telstra network and comes with a non-user-replaceable 3000 mAh Li-ion battery. It also features LED indicators for power, Wi-Fi, and network connection. The device meets safety standards with a SAR rating of 1.886 W/Kg, 10g average and 5mm spacing. It is manufactured by ZTE, with the model number MF986C.

Using The Telstra 4GX Wi-Fi Plus 2 External Antenna Ports

The Telstra 4GX Wi-Fi Plus 2 modem is equipped with two external TS9 antenna connectors, designed to enhance your device's coverage and data rates. Please note that these antennas are specifically for the Telstra network connection and do not affect your device's Wi-Fi performance.

When using an external antenna, follow these guidelines:

• If you have a single antenna, insert it into port 1, which is the main antenna.
• If you have a dual antenna, use both ports 1 and 2 for optimal coverage.

Remember to handle the antenna leads with care. The connectors are small and delicate, and rough treatment, harsh pulling, or bending can cause damage.
